CPM 3-9 oil-injected screw compressors

The CPM leaves piston compressors behind

While piston compressors are often considered a good starter option, the CPM 3-9 actually offers many more benefits. Here are some:

Better performance: The CPM generates more air and does so while using less energy and lowering operating costs.

Longer working hours: While pistons need to cool down frequently, the CPM can run around the clock.

Cleaner air: An oil carry-over of less than 5 ppm allows the CPM to generate much cleaner air than a typical piston compressor (more than 30 ppm). This protects pneumatic tools and end products.

Lower sound levels: Piston compressors are typically 20 decibels louder than the CPM, which can make them subject to noise protection regulations.

The all-in-one workshop compressor

Combining its trademark sturdiness, efficiency and versatility, CP has designed a small rotary screw compressor that checks all the boxes for growing businesses. With its low noise levels, continuous operation and cleaner air, the CPM 3-9 outperforms traditional piston compressors.

Easy to use

Intuitive controller

Removable panel for easy service

More air, lower energy costs

Get 15% more air using 12% less energy compared to its predecessor

Enjoy continuous use without cool-down periods

An all-in-one solution

The CPM is a complete air system in one compact unit. Even options such as an air dryer, an air receiver or an oil heater are fully integrated to help you save on floor space and operational costs

Built to last

The CSM is built in Europe. Its automated screw air end manufacturing line prevents human error and ensures the CSM is as powerful and reliable in real life as it was designed

Comfortably quiet

The CPM 3-9 was built to be installed and used right where you need it: on your shop floor. That is why we made the unit extra quiet. With a sound level as low as 61 dB(A), the CPM is comparable to a household appliance

Five top benefits of the CPM 3-9

Efficiency: Uses less (-12%) energy than its predecessor to lower operating costs.
Reliability: Built-to-last in Europe, the CPM works dependably even in tough conditions, thanks to its quality components and sturdy design.
Ease of use: It takes only one person to install the CPM. Using it is just as easy. An intuitive controller with service indications and visible alerts ensures that even a non-expert operator is always on top of things and can keep the compressor in optimal working order.
An all-in-one solution: The CPM is a complete air system in one compact unit. Even options such as an air dryer, an air receiver or an oil heater are fully integrated to help save on floor space and operational costs.
Low noise: The super-silent CPM can be installed right on your shop floor, eliminating the need for an expensive compressor room and a network of pipes.

CP_CPM_3-9_EN_6999 6105 61_LR 5 MB, PDF

Technical specifications
Max. working pressure	8 - 10 Bar
Reference working pressure	7.5 - 9.5 Bar
Free Air Delivery @ reference conditions*	294 - 1062 l/min
Motor power	3 - 10 HP
Noise level **	61 - 68 db(A)

CPM: convincing statistics

5 – The CPM delivers a very low oil carry-over of only 5 ppm, which protects air-powered tools and the quality of end products.

12 – The CPM series is 12% more efficient than its predecessors.

15 – The next-generation drive train delivers 15% more air.

24/7 – While piston compressors require frequent cool-down breaks, the CPM can work around the clock thanks to its rotary screw technology.

46 – The CPM will reliably deliver quality air even in ambient temperatures of up to 46°C.

61 – Thanks to its super-silent engineering, the CPM is as quiet as a household appliance. That low sound level of 61-68 dB(A) means the compressor can be installed near the point of use, which eliminates efficiencies and the need for a separate compressor room.
