CPD/CPE Series - Oil-injected screw compressors
The CPD/CPE series offers high quality and reliable screw compressors ranging from 30 to 75 kW. Thanks to the low noise levels, the range can easily be placed into your work environment.
CPD/CPE 30 kW - 90 kW oil-injected screw compressors series is built on a trustworthy technology which increases it's efficiency and makes the CPD/CPE screw compressors a reliable performer. These ranges are also suitable for more demanding applications and can be deployed in harsh working conditions.
Key benefits of the CPD/CPE series
The CPD/CPE series is designed with Chicago Pneumatic in-house design elements, which guarantees the quality of the compressed air and efficient operations. It includes separate coolers, air filter and an integrated fan.
Thanks to the low noise levels of the CPD/CPE screw compressor, it can be installed next to your workplace without disturbing the environment.
The key benefits include the integration of the ES4000 T controller with intelligent connectivity. A unique touch control unit, professionally programmed for intelligent monitoring and connectivity .
We protect your efficiency
Energy costs represent about 70% of the total operating cost of your compressor over a 5 year period. That’s why reducing the operating cost of a compressed air solution is a major focus. Variable frequency driven compressors can cut the energy bill of your compressor by up to 35%.
Technical Specifications
CPD/CPE series 30-90 kW 50 Hz
| Model | Pressure |
Motor |
Capacity* |
Noise |
Connection |
Dimensions | ||||
|
Mpa |
hp |
kW |
I/s |
cfm |
dB(A)±2 |
G |
Length (mm) | Width (mm) | Height (mm) |
CPD 40 G |
0.7 | 40 |
30 |
94 |
198 |
69 |
1 1/2 |
1723 | 980 | 1600 |
|
0.8 |
40 |
30 |
89 |
185 |
69 |
1 1/2 |
1723 | 980 | 1600 |
|
1 |
40 | 30 | 79 |
168 |
69 |
1 1/2 |
1723 | 980 | 1600 |
CPD 50 G |
0.7 |
50 |
37 |
113 |
240 |
70 |
1 1/2 |
1723 | 980 | 1600 |
| 0.8 | 50 | 37 | 106 | 223 | 70 | 1 1/2 | 1723 | 980 | 1600 | |
| 1 | 50 | 37 | 97 | 206 | 70 | 1 1/2 | 1723 | 980 | 1600 | |
| CPD 60 G |
0.7 | 60 | 45 | 133 | 281 | 70 | 1 1/2 | 1723 | 980 | 1600 |
| 0.8 | 60 | 45 | 133 | 281 | 70 | 1 1/2 | 1723 | 980 | 1600 | |
| 1 | 60 | 45 | 114 | 241 | 70 | 1 1/2 | 1723 | 980 | 1600 | |
| CPE 75 | 0.7 | 75 | 55 | 187 | 396 | 75 | 2 | 1656 | 1089 | 1840 |
| 0.8 | 75 | 55 | 177 | 375 | 75 | 2 | 1656 | 1089 | 1840 | |
| 1 | 75 | 55 | 153 | 325 | 75 | 2 | 1656 | 1089 | 1840 | |
| 1.25 | 75 | 55 | 137 | 289 | 75 | 2 | 1656 | 1089 | 1840 | |
| CPE 100 | 0.7 | 100 | 75 | 248 | 526 | 74 | 2 | 1756 | 1089 | 1840 |
| 0.8 | 100 | 75 | 235 | 498 | 74 | 2 | 1756 | 1089 | 1840 | |
| 1 | 100 | 75 | 204 | 433 | 74 | 2 | 1756 | 1089 | 1840 | |
| 1.25 | 100 | 75 | 177 | 375 | 74 | 2 | 1756 | 1089 | 1840 | |
| CPE 120 | 0.7 | 120 | 90 | 282 | 598 | 75 | 2 | 1756 | 1089 | 1840 |
| 0.8 | 120 | 90 | 269 | 570 | 75 | 2 | 1756 | 1089 | 1840 | |
| 1 | 120 | 90 | 240 | 508 | 75 | 2 | 1756 | 1089 | 1840 | |
| 1.25 | 120 | 90 | 297 | 438 | 75 | 2 | 1756 | 1089 | 1840 | |
